Full specifications

Brand	iTel
Inverter Specifications
Model	IHY-6K6L1C
Inverter type	Hybrid
Grid type	Single Phase
IP class	IP66
Warranty	5 Years
PV Input Data
Max DC input power	13200 W
PV input voltage	500 V
MPPT voltage range	60-425 V
Max. PV input current	20 A
No. of MPPT	2
No. of strings per MPPT	1
Startup voltage	60 V
AC Output Data
Rated AC output	6600 W
Rated AC output current	30 A
Rated voltage	230 V
Smart load / generator input	Yes
Parallel operation	Yes
Battery Data
Battery type	Lithium & Lead-Acid
Battery voltage range	40-60 V
Max. charging current	140 A
Max. discharging current	140 A
BMS	WiFi / RS485 / CAN / Dry-contact
Protections
AC overcurrent protection	Yes
Output short circuit protection	Yes
Surge protection	Yes
Over voltage protection	Yes
General Specifications
Weight	15 kg
Operating temperature	-40°C ~ +60°C
Size (W×H×D)	309 × 420 × 180 mm

Note: 6600 W and 6600 VA on a 48 V battery bank (40 to 60 V, lead-acid, lithium or user-defined) from up to 13,200 W of PV, double the output, across two MPPTs at 20 A each, one string per tracker, on a 60 to 425 V window with a 500 V ceiling and a 60 V start, so short strings still wake it early. 140 A charging from solar and 140 A from mains or generator, with 140 A discharge. Output is 220/230/240 V at 50/60 Hz with up to 30 A and under 3% harmonic distortion. It runs continuously between 100% and 110% of rating unless over-temperature protection trips, then holds 110 to 140% for 10 seconds and 140 to 200% for 7 seconds, with a 13,200 VA surge for 5 seconds. Switchover is under 20 ms in appliance mode. AC input accepts 90 to 280 V and passes up to 50 A in bypass. The datasheet lists on-grid output alongside smart-load and backup outputs, plus a time-of-use mode for peak and off-peak tariffs, but its certification line is IEC 62109-1, IEC 62109-2 and IEC 61683 only. The IEC 62116 anti-islanding and IEC 61727 grid-connection standards a net-metering application normally needs are not listed, so confirm with your installer before counting on net metering. The sheet publishes 99.9% MPPT tracking and over 93% battery-mode conversion but no PV-to-AC efficiency, so the efficiency field is left empty rather than filled with a number that measures something else. Against the IHY-6KL1A: 600 W more output, 1200 W more PV, 20 A instead of 18 A per tracker, 140 A instead of 120 A of charging and 15 kg instead of 20 kg, but the 6KL1A's sheet carries the IEC 62116 and IEC 61727 grid certifications and this one does not. Supports a diesel generator and a smart load, and parallels to 12 units. WiFi, RS485, CAN and dry contact. IP66, fan-cooled at under 55 dB, rated -40 to +60 °C with derating above 45 °C, up to 3000 m with derating above 2000 m. Protection covers overvoltage, overload, short circuit and over-temperature, with Type II surge protection on the DC side and Type III on the AC side. 15 kg in a 309 × 180 × 420 mm case (length × width × height on the sheet). 5-year replacement warranty. Price shown is the w11stop.com listing, Rs 195,000 (in stock), read 22 September 2026. Kamal Solar lists it at Rs 200,000.
