inverex nitrox 10kw 3p 5g ongrid

Inverex Nitrox 10kW 3Ph-5G On-Grid Inverter Price in Pakistan

Rs 235,000 – Rs 262,500
Rs 23,500 per kW
Price updated: 16 September 2026
Compare this modelDownload datasheet (PDF)

Full specifications

Brand
Inverter Specifications
ModelNITROX 10KW 3Ph-5G
Inverter typeOn-Grid
Grid typeThree Phase
IP classIP65
Warranty10 Years
PV Input Data
Max DC input power13000 W
PV input voltage1000 V
MPPT voltage range200-850 V
No. of MPPT2
No. of strings per MPPT2
Startup voltage250 V
AC Output Data
Rated AC output10000 W
Rated AC output current14.5 A
Power factor0.8 leading to 0.8 lagging
Battery Data
Battery typeNone (on-grid)
Protections
PV reverse polarity detectionYes
Insulation resistance detectionYes
AC overcurrent protectionYes
Output short circuit protectionYes
Surge protectionYes
Over voltage protectionYes
General Specifications
Weight10 kg
Operating temperature-25°C ~ +65°C
Max. efficiency98.6%
Size (W×H×D)330 × 508 × 206 mm
