GoodWe GW10K-ET-L-G10 10kW Hybrid Inverter

Rs 475,000 – Rs 480,000
Rs 47,500 per kW
Price updated: 11 August 2026
Compare this modelDownload datasheet (PDF)

Full specifications

Brand
Inverter Specifications
ModelGW10K-ET-L-G10
Inverter typeHybrid
Grid typeThree Phase
IP classIP66
PV Input Data
Max DC input power20000 W
PV input voltage1000 V
MPPT voltage range150-850 V
Max. PV input current20 A
No. of MPPT3
No. of strings per MPPT1
Startup voltage180 V
AC Output Data
Rated AC output10000 W
Rated AC output current14.5 A
Rated voltage400 V
Smart load / generator inputYes
Power factor~1 (adjustable from 0.8 leading to 0.8 lagging)
Battery Data
Battery voltage range40-60 V
Max. charging current220 A
Max. discharging current220 A
BMSCAN
Protections
PV reverse polarity detectionYes
Insulation resistance detectionYes
Leakage current detectionYes
AC overcurrent protectionYes
Output short circuit protectionYes
Surge protectionYes
Over voltage protectionYes
General Specifications
Weight45.3 kg
Operating temperature-35°C ~ +60°C
Max. efficiency97.8%
Size (W×H×D)551 × 756 × 258 mm
