Full specifications

Brand	Fronus
Inverter Specifications
Model	X3-PRO-20K-G2
Inverter type	On-Grid
Grid type	Three Phase
IP class	IP66
PV Input Data
Max DC input power	30000 W
PV input voltage	1100 V
MPPT voltage range	160-980 V
Max. PV input current	32 A
No. of MPPT	2
No. of strings per MPPT	2
Startup voltage	200 V
AC Output Data
Rated AC output	20000 W
Rated AC output current	29 A
Rated voltage	400 V
Power factor	0.8 leading to 0.8 lagging
Battery Data
Battery type	None (on-grid)
Protections
PV reverse polarity detection	Yes
Insulation resistance detection	Yes
Leakage current detection	Yes
AC overcurrent protection	Yes
Output short circuit protection	Yes
Surge protection	Yes
Over voltage protection	Yes
General Specifications
Weight	26 kg
Operating temperature	-30°C ~ +60°C
Max. efficiency	98.30%
Size (W×H×D)	482 × 417 × 181 mm

Note: Grid-tie only - no battery, no backup. Steps up from the X3-MIC on every input figure: 1100 V DC ceiling against 1000 V, 32 A per tracker against 16 A, and two strings per tracker as standard (32/32 A across 2 MPPTs here). MPPT window 160-980 V, nominal 650 V. Maximum apparent power 22000 VA, maximum output current 33.6 A. Peak efficiency 98.30%, European 97.80%. 26 kg, IP66, -30 to +60 degC, altitude to 4000 m. Natural cooling on the smaller units and smart fan cooling higher up; typical noise under 55 dB. AFCI and AC auxiliary supply are optional.
