Crown Yorker 2kW Hybrid Inverter Price in Pakistan
Price on request
Full specifications
| Brand | Crown |
| Inverter Specifications | |
| Model | CSE-Y2K12VP1 |
| Inverter type | Hybrid |
| Grid type | Single Phase |
| PV Input Data | |
| Max DC input power | 3000 W |
| PV input voltage | 450 V |
| MPPT voltage range | 30-400 V |
| Max. PV input current | 18 A |
| AC Output Data | |
| Rated AC output | 2000 W |
| Rated voltage | 230 V |
| Power factor | 1 |
| Battery Data | |
| Battery type | Lithium & Lead-Acid |
| Battery voltage range | 10.5-16 V |
| Max. charging current | 100 A |
| BMS | RS485 / CAN / RS232, Wi-Fi |
| Protections | |
| AC overcurrent protection | Yes |
| Output short circuit protection | Yes |
| General Specifications | |
| Weight | 4.5 kg |
| Operating temperature | -10°C ~ 60°C |
| Size (W×H×D) | 338 × 268 × 104 mm |
Note: 2000 W from PV and battery together, but only 1600 W from the battery alone, which is the number that matters on a cloudy day or at night. Up to 3000 W of PV over a 30 to 400 V MPPT window on a 450 V ceiling, 18 A of PV input current, and 100 A of charging on a 12 V battery bank (10.5 to 16 V). Output 230 V at power factor 1, AC input up to 17 A, protected by a 17 A breaker. Crown call it a hybrid and it runs without a battery, but the datasheet has no grid-tie or feed-in section, so do not plan a net-metering application around it. RS485, CAN and RS232 with Wi-Fi monitoring, and a TI28 series DSP. Rated -10 to 60 degC, 4.5 kg. The datasheet prints the case as 338 x 268 x 104 mm without naming which figure is which axis. The unit in Crown's own product image carries an IP20 marking, which would make it strictly indoor, but no IP row appears on the datasheet so the field is left empty. No price yet: w11stop.com lists four Crown Yorker inverters and this is not one of them, read 26 September 2026.
